ELCO flexible couplings for effective damping of shocks and vibrations.
![ELCO flexible couplings for effective damping of shocks and vibrations.](https://www.renk.com/_Resources/Persistent/c/8/8/3/c883dc720063ad7d1d6c7401c3f06f064a86301e/renk-coupling-ELCO-01-997x561-996x561.png)
The torsionally resilient, flexible coupling is responsible for effectively dampening the shocks and vibrations that occur in drive systems during operation. Due to the special spring and damping properties of the profiled coupling sleeves, ELCO effectively limits torsional vibrations. The special design ensures the failsafe and consistent transmission of torque. In addition, it permits limited radial and angular misalignments of the shafts being connected and absorbs longitudinal displacements.
Due to the adaptability and high-quality design, RENK ELCO couplings have proven in tens of thousands of drives used in conventional energy production, in mining and hydropower, as well as in the oil, gas, and the petrochemical industry.
![Flexible coupling ELCO in production](https://www.renk.com/_Resources/Persistent/0/3/0/9/03093167d3f0a43f3e061a8609b56a7c2c33e0f6/EM2_8573-4581x3434-760x570.jpg)
A flexible coupling with a rugged design and ready for various application.
The coupling flanges of the adaptable ELCO coupling consist of steel or a special material. The standard design has one-sided or alternately arranged transmission elements, but special designs are also possible. The sleeve material is usually made from a modified natural rubber, alternatively from chloroprene polymer or nitrile rubber.
- Design: Standard design with one-sided or alternately arranged transmission elements, special designs
- Sleeve material: Modified natural rubber, chloroprene polymer or nitrile rubber
![Design flexible coupling side view](https://www.renk.com/_Resources/Persistent/5/7/4/f/574fb2c86410bd2882f0f942f570016980315a8e/renk-coupling-ELCO-17-867x487-867x482.png)
Features
- Particularly good torsion spring and damping properties
- Reduction of torque and speed shocks
- Reduction of torsional vibrations
- Failsafe and consistent transmission of torque
- Compensation of radial and angular misalignments
- Compensation of longitudinal displacements
- Easy axial removal of the profile sleeves and bolts
Technical Data
Shaft diameter: | 10 to 500 mm |
Coupling torque: | 18 to 540,000 Nm |
Construction: | Standard construction with Single-side or alternating-side transmission elements, special construction |
Coupling material: | Steel or special material |
Sleeve material: | Modified natural rubber, chloroprene polymerizate or nitrile rubber |
