Transmissions
HSWL 256 EVO
The HSWL 256 EVO transmission offers superior maneuverability due to the 6 speed transmission and fast pivot turn capability. The system features the M82 electric motor generator, providing additional mobility and power generation capabilities to the vehicle platform. The HSWL 256 EVO also includes Drive-By-Wire functionality.
Featuring the latest developments within its class, this modern, high performing transmission offers extraordinary reliability for mission and crew assurance and meets all the requirements of the latest generation, complete with excellent brake performance, digital control and emergency operation.
Features
- Fully integrated M82 electric motor generator
- Front or rear vehicle installation
- Compact and lightweight
- Flexible transmission design for electric drive and drive-by-wire
- Digital electronic control and monitoring
Technical Data
| Dimensions: | 1,540 x 765 x 825 mm |
| Maximum engine power: | 850 kW (1,150 HP)–885 kW (Boost) |
| Vehicle weight, typical: | 35–55 t |
| Power shift transmission: | 6 speed forward, 6 speed reverse |
| Overall ratio, mechanical: | 6.3 |
| Stall torque ratio: | 2.3 |
| Transmission weight (without oil filling): | 1,750 kg |
| Brake system: | Fully integrated, high performance |
| Steering system: | Integrated, high maneuverability |
